Honda Civic Type R ,EK9
  • 0

#2 Braco

Braco

    Advanced Member

  • Members
  • PipPipPip
  • 110 posts
  • Location:Split
  • Vozilo:Honda Civic 1.4 iS

Posted 10 December 2007 - 13:32

1.jpg 2.jpg 3.jpg 4.jpg 5.jpg 6.jpg 7.jpg 8.jpg 9.jpg Riječi su suviĀšne , slijedi nastavak ;)
  • 0
Posted Image

#3 Braco

Braco

    Advanced Member

  • Members
  • PipPipPip
  • 110 posts
  • Location:Split
  • Vozilo:Honda Civic 1.4 iS

Posted 10 December 2007 - 13:43

EK-9 SPECIFICATIONS

Dimensions & Weight

Length / Width / Height (mm)
4185 / 1695 /1360
Indoorsize Length/Width/Height (mm)
1695 /1390 / 1115
Wheel base (mm)
2620
Track (Fr / Rr)
1480 / 1480
Minimum Ground Clearance (mm)
135
Curb Weight (kg)
1090
Seating
4

Engine

Engine Form
B16B
Engine Type
l-4 DOHC VTEC
Displacement (cc)
1595
Horsepower (PS/rpm)
185 / 8200
Torque (kgm/rpm)
16.3 /7500
Fuel capacity (liter)
45
Transmission
5MT


Performance figures for JDM Honda Civic Type-R

Have you ever wondered how fast the Honda Civic Type-R is in a straightline ? In the May 1998 issue of UK's Performance Car, a true JDM Honda Civic Type-R was tested in a special hot-hatches feature. The figures attained will send shivers down any of our competitor's spines.

A listing of some of the critical standing acceleration numbers are as follow:

0-60mph : 5.7 seconds
0-100mph: 17.5 seconds
0-1/4mi : 15.0 seconds at 94mph

Top speed was not tested as all JDM Hondas are speed limited to around 180-190kph.

The Civic Type-R bested the UK version of the Honda Integra Type-R which has a derated 190hp engine (and similar quad headlights front facial of the US version). The UK's Integra Type-R obtained values of around 6.2seconds for the 0-60mph dash but a faster 17.1 seconds for the 0-100mph dash. However, the Integra Type-R was not fully run-in at the time of its test.

Highlights of B16B 98 Spec R compared to B16A


The translations for the numbered labels in the diagram are:

1. Cylinder Head - Complete port & polish
2. Exhaust Valve Spring - High-lift, dual-layered spring
3. Sparkplug - High-heat-type #7 platinum plug
4. Pistons - High-compression, low-friction, custom pistons
5. Connecting Rod - High-output, high-durability, lightened, custom conrod
6. Engine Stiffener - Aluminum die-cast, high-durability, one-piece type
7. Crankshaft - Full-balancer, 8-weight, high-output, custom crankshaft
8. Inlet Valves - Lightened inlet valves
9. Inlet Valve Springs - High-lift, flat-surfaced, dual-layered spring
10. Camshaft - Wide-angled, high-lift, high-durability camshaft
11. Intake Manifold - High-RPM type.

In order to increase the power output by 15 hp, and the max RPM by 200RPM, the engine goes through many upgrades. It should be noted that the B18C spec.R's cylinder block is used for its endurance.

Engine specifications between B16A and B16B.


The camshaft profiles (wild cam) change from B16A 160ps to 170ps and finally to B16B are :


pistons.jpg Different pistons are responsible for the compression ratio increases between 160ps & 170ps B16A and the 10.8 ratio for B16B. Readily apparent is the relatively modest change in piston top between B16A 160ps and B16A 170ps for the 10.2 to 10.4 change. However, the radically different piston top for B16B is very clear from the picture. The increase in compression ratio between B16B from B16A is 0.4.
The cut-outs on the piston top to accomodate for valve lift are basically the same between all three piston. This could meant that B16B camshafts can be installed into both 160ps and 170ps B16A without the need to change to B16B pistons.

porthead.jpg On B16B, the inlet ports are manually ported to increase air-flow. The exhaust ports are identical to B16A.
B16B intake valve seats are at a different angle to B16A, 45 degrees vs 60 degrees. The intake valves are also different, being lighter and having a thinner valve stem.

004_005.gif 004_006.jpg

On the left are the power curves for B16A 170ps versus B16B. Note the big gain in power after 6000rpm, the VTEC switch-over point between mild and wild cam profiles. The gain at extreme high rpms is readily apparent on the curves.

Various individual specifications for B16B can teach us about the feasibility of various modifications to B16A. For eg, the throttle bore diameter for B16B is identical to B16A at 60mm. This means that enlarged throttle bodies for B16A might not be an optimal mod or that a compromise in power delivery might result, eg loss of low-end power in return for gain in high-end power. Note that B16B has identical low and mid range power as B16A.

As with B18C Spec R, the wonder of B16B is the assurance of a 15 to 25ps gain in power on a B16A provided the tuning done by Honda can be completely replicated. Nevertheless even if only a portion can be duplicated, combining with properly designed aftermarket exhaust, headers, and intake could still potentially realize this 15ps gain. B16B engine parts are available from Honda and with care, most of them can be used on B16A for good power gains.

B16B_PCTX_profile.jpg B16A_PR3_profile.jpg
B16B_PCTX_spec.jpg B16A_PR3_spec.jpg

NH-0 - Championship white
Y-56 - Sunlight Yellow
NH-583M - Vogue Silver Metallic
NH-592P - Flamenco Black Pri Metallic Clearcoat
